Spraying
Enable Enable
Enable
Hose Hose
Hose
Resistance Resistance
Resistance
Mode Mode
Mode
Thismoderequiresacalibrationfactortorun(see
CalibrationProcedure,page57).
1.EnterSetupModeandnavigatetoSystem
screen3.
2.SelectResistancefromthedrop-downmenu.
NOTE: NOTE:
NOTE:
Ifnocalibrationfactorisshown,followthe
CalibrationProcedure,page57.
NOTICE NOTICE
NOTICE
Topreventdamagetotheheatedhose,ahose
calibrationisrequiredifanyofthefollowing
conditionsaretrue:
•Thehosehasneverbeencalibratedbefore.
•Asectionofhosehasbeenreplaced.
•Asectionofhosehasbeenadded.
•Asectionofhosehasbeenremoved.
3.EnterRunModeandnavigatetotheTargets
screen.Usetheupanddownarrowstosetthe
desiredtemperature.
NOTE: NOTE:
NOTE:
HoseResistanceModecontrolsthe
average󰘱uidtemperatureoftheAandB󰘱uid.
Setthehosetemperaturesetpointhalfway
betweentheAandBtemperaturesetpoints
andadjustasneededtoachievedesired
performance.
4.NavigatebacktotheRunModehomescreen.
TheHoseResistanceModeiconwilldisplay.
NOTE: NOTE:
NOTE:
WhenHoseResistanceModeisenabled
andthehoseheatisoff,thehosetemperature
willdisplay“---”.InHoseResistanceMode,
temperaturevaluesareonlydisplayedwhenthe
heatison.
Disable Disable
Disable
Hose Hose
Hose
Resistance Resistance
Resistance
Mode Mode
Mode
1.EnterSetupmode.
2.NavigatetoSystemscreen3.
3.SettheHoseControlModetoFTS.
334945J 55
