FluidCirculation
Circulation Circulation
Circulation
Through Through
Through
Gun Gun
Gun
Manifold Manifold
Manifold
NOTICE NOTICE
NOTICE
Topreventequipmentdamage,donotcirculate
󰘱uidcontainingablowingagentwithoutconsulting
withyourmaterialsupplierregarding󰘱uid
temperaturelimits.
NOTE: NOTE:
NOTE:
Optimumheattransferisachievedatlower
󰘱uid󰘱owrateswithtemperaturesetpointsatdesired
drumtemperature.Lowtemperaturerisedeviation
errorsmayresult.
Circulating󰘱uidthroughthegunmanifoldallows
rapidpreheatingofthehose.
1.Installgun󰘱uidmanifold(P)onaccessory
circulationkit(CK).Connecthighpressure
circulationlines(R)tocirculationmanifold.
The Fusion AP gun manifold is shown.
CK CK
CK
Gun Gun
Gun
Manual Manual
Manual
246362FusionAP309818
256566
FusionCS
313058
2.Routecirculationlinesbacktorespective
componentAorBsupplydrum.Use
hosesratedforthemaximumworking
pressureofthisequipment.See
TechnicalSpeci󰘰cations,page76.
3.FollowproceduresfromStartup,page47.
4.Turnmainpowerswitchon.
5.Settemperaturetargets.See
TargetsScreen,page42.
6.Beforestartingthemotor,unlockthehydraulic
compensatorknob,thenrotatecounter-clockwise
untilitceasestomove.
7.Pressmotortostartmotorandpumps.
Circulate󰘱uidatlowestpossiblepressureuntil
temperaturesreachtargets.
8.Press
toturnonthehoseheatzone.
9.TurnontheAandBheatzones.Waituntilthe
󰘱uidinletvalvetemperaturegauges(FTG)reach
theminimumchemicaltemperaturefromthe
supplydrums.
10.Turnoffmotor.
334945J 51
