Spraying
Hose Hose
Hose
Control Control
Control
Modes Modes
Modes
ThehoseFTSmustbeconnectedinallmodesto
reducetheriskofstaticsparking.Staticsparking
cancausefumestoigniteorexplode.Grounding
providesanescapewirefortheelectriccurrent.
IfthesystemproducestheT6DHsensorerror
alarmortheT6DTsensorTCMalarm,useHose
ManualModeuntilthehoseRTDcableorFTScan
berepaired,oruseHoseResistanceModewitha
properlysavedcalibrationfactor.
DonotuseHoseManualModeforextendedperiods
oftime.Thesystemperformsbestwhenusedin
HoseFTSModeorHoseResistanceMode.Onlyuse
HoseResistanceModewithgenuineGracoheated
hoses.
Hose Hose
Hose
Control Control
Control
Mode Mode
Mode
Description Description
Description
FTSThe󰘱uidtemperaturesensor(FTS)
installedinthehoseautomatically
controlsthehose󰘱uidtemperature.
ThismoderequirestheFTStobe
installedandworkingproperly.
ResistanceThehoseheaterelementresistance
automaticallycontrolsthehose
󰘱uidtemperature.Thismode
requiresacalibrationfactor(see
CalibrationProcedure,page57).
ManualThesystemsuppliesasetamount
ofhosecurrent(amps)toheat
thehose.Thehosecurrentisset
bytheuser.Thismodehasno
pre-programmedcontrolandis
designedtobeusedforalimited
amountoftimeuntiltheFTS
issuesare󰘰xed,oracalibration
factorisproperlysaved(see
CalibrationProcedure,page57).
54 334945J
