TYPICAL OLDER 1703 SERIES, MODELS 21 AMPS AND BELOW
Customer Connections
4TB4 Customer Terminal Strip
F1 and F2 Fuses
Input Power Line Terminal Strip
Motor Terminal Strip
Drive/Off/Line/Test Switch
(optional)
Older drives were built as shown here. Newer drives of
21 amps or below do not have a separate power board.
The customer connections for these drives and all
drives larger than 21 amps are shown on page 6.
