EN - 13
1. Fuel Tank and Cap
2. Fuel Level Window
3. Oil Filter
4. Oil Drain
5. Engine Oil Dipstick
6. Air Filter
7. Ignition Key
8. Choke Control Knob
9. Throttle Control Lever
10. Power Take-off (PTO) Knob
11. Hour Meter
12. Height-of-Cut Adjustment System
13. Transport Lock Release Lever
14. Deck Lift Pedal
15. Rollover Protection Structure (ROPS)
16. Seat Adjustment Lever
17. Seat Latch
18. Parking Brake Lever
19. Belt Cover (2)
20. Steering Lever (2)
21. Discharge Chute
22. Anti-Scalp Wheel (6)
23. Transaxle Bypass Lever (2)
24. Battery (Under Seat)
25. Fuse Box
26. Hydraulic Oil Expansion Tank (2)
CONTROLS AND FEATURES
Figure 6
16
9
1
23
10
11
7
8
26
25
17
24
5
3
4
6
2
22
19
15
18
20
13
12
14
21
To Next Page
