Gree GMV5 Service Manual

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
10
Outdoor Units_Heat Pump
－
6Ton
8Ton
10Ton
Model
－
GMV-Y72WM/C
-F(U)
GMV-Y96WM/C
-F(U)
GMV-Y120WM/C
-F(U)
Size of liquid pipe in. Φ3/8 Φ3/8 Φ1/2
Size of oil-balanced pipe
in.
Φ3/8
Φ3/8
Φ3/8
Outline
dimension(WxDxH)
in.
36-5/8x30
-1/8x63-1/4
52-3/4x30
-1/8x63-1/4
52-3/4x30
-1/8x63-1/4
Packing size(WxDxH) in.
39-3/4x33
-1/8x69-7/8
55-7/8x33
-1/8x69-7/8
55-7/8x33
-1/8x69-7/8
Net weight
(Not include converter)
LBS
487 650 650
Gross weight
(Not include converter)
LBS
514 683 683
Outdoor Units_Heat Pump
－
12Ton
14Ton
16Ton
Model
－
GMV-Y144WM/C-F(U)
GMV-Y168WM/C-F(U)
GMV-Y192WM/C-F(U)
Module (combinated)
－
GMV-Y72WM/C-F(
U)+
GMV-Y72WM/C-F(U)
GMV-Y72WM/C-F(U)+GM
V-Y96WM/C-F(U)
GMV-Y96WM/C-
F(U)+
GMV-Y96WM/C-F(U)
Cooling capacity
Btu/h
144000
168000
192000
Heating capacity
Btu/h
162000
189000
216000
Air volume
CFM
6710+6710
6710+8240
8240+8240
Max. external static
pressure
Pa 82 82 82
Power
－
208/240V 3~ 60Hz
208/240V 3~ 60Hz
208/240V 3~ 60Hz
Input power for cooling
kW
5.45+5.45 5.45+7.30 7.30+7.30
Input power for heating
kW
5.80+5.80 5.80+7.85 7.85+7.85
Input current for cooling
A
16.42+16.42
16.42+20.37
20.37+20.37
Input current for heating
A
17.29+17.29 17.29+23.50 23.50+23.50
MOP A
208V:45+45
240V:40+40
208V:45+45
240V:40+40
208V:45+45
240V:40+40
MCA A
208V:35.3+35.3
240V:30.3+30.3
208V:35.3+43.6
240V:30.3+37.3
208V:43.6+43.6
240V:37.3+37.3
Refrigeration oil no. of
compressor
－
FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H
Ambient temperature range
for cooling
℉
23~125.6 23~125.6 23~125.6
Ambient temperature range
of heating
℉
-4~75.2 -4~75.2 -4~75.2
Refrigerant type
－
R410A
R410A
R410A
Charging volume of
refrigerant
oz 229.3+229.3 229.3+398.6 398.6+398.6
Max. quantity of connected
indoor unit
unit 23 29 33
Size of gas pipe
in.
Φ1-1/8
Φ1-1/8
Φ1-1/8
Size of liquid pipe
in.
Φ1/2
Φ5/8
Φ5/8
Size of oil-balanced pipe
in.
Φ3/8
Φ3/8
Φ3/8
Outline dimension(WxDxH) in.
(36-5/8x30-1/8x63-1/4)
x2
(36-5/8x30-1/8x63-1/4)
+(52-3/4x30-1/8x63-1/4)
(52-3/4x30-1/8x63-1/4)
x2
Packing size(WxDxH)
in.
/
/
/
Net weight
(Not include converter)
LBS 487+487 487+650 650+650
Gross weight
(Not include converter)
LBS 514+514 514+683 683+683
