Gree GMV5 Service Manual

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
314
No.
Name of part
Part code
Quantity
17
One way Valve
'04324001
2
18
Electronic Expansion Valve
'43044100172
1
19
Bidirection Strainer
'07210044
1
20
Gas Tube Filter
'072190511
2
21
Plate-Type Heat Exchanger
'00904100005
1
22
Right Side Plate
'01314713P
1
23
Base Frame Assy
'000043060031
1
24
Gas-Liquid Separator
'07424188
1
25
Oil Separator
'0742418601
1
26
Cut off Valve
'07334100011
2
27
Cut off Valve
'07334100012
1
28
Cut off Valve
'07130239
1
29
Top Cover
'01264231P
2
30
Front Panel(Up)
'01544620P
1
31
Handle
'26904100016
2
32
Front Panel
'0154462701P
1
33
Sensor Sub-Assy
' 390002000050
1
34
Magnet Coil (Electromagnetic Valve)
' 4304800001902
1
35
4 Way Valve Coil
'43048000018
1
36
Magnet Coil (Electromagnetic Valve)
' 4304800001901
1
37
Magnet Coil (Electromagnetic Valve)
'43048000019
1
38
Electric Expand Valve Fitting
'4304413203
1
39
Electric Expand Valve Fitting
'4304413204
1
40
Pressure Sensor
'32218000009
1
41
Pressure Sensor
'32218000008
1
42
Electrical Heater(Compressor)
'76614100002
1
43
Electrical Heater(Compressor)
'76614100001
1
44
Left Side Plate
'01314712P
1
45
Compressor and Fittings
'00204100008
1
46
Oil Separator
'07424100023
1
47
Pressure Protect Switch
'4602000910
1
48
Electric Box Assy
'100002065752
1
49
Main Board
'300027000526
2
50
Main Board
'300027000397
1
51
Main Board
'300027000272
1
52
Power Switch
'300027060351
1
Above data is subject to change without notice,pls reference the SP in global service website.
