Table 1
91KX rellortnoC etomeR deriW
No. Symbols Description
1
Swing function.
2
Sleep function.
3
4
Running modes of the indoor unit (Cooling, Dry, Fan and Heating).
Defrosting function for the outdoor unit.
5
Gate-control function
6
Lock function.
7
High, middle, low or auto fan speed of the indoor unit.
8
9
10
Turbo function.
11
12
Shield functions (buttons, temperature, On/Off or Mode is shielded
by the remote monitor.
Memory function (The indoor unit resumes the original setting state
after power failure and then power recovery).
It blinks under on state of the unit without operation of any button.
13
Energy-saving function.
14
Ambient/preset temperature value.
15
Electric auxiliary heating function.
16
Blow function.
17
Master wired remote controller (this function is yet unavailable for
this unit).
Timing value.
18 Quiet function (two types: quiet and auto quiet)
19 SET It will be displayed under the debugging mode.
2 Buttons
2.1 Buttons on the Wired Remote Controller
Fan
Mode
Function
On/Off
Timer
1 2 3
4
5
6
7
8
Fig. 3 Buttons on the Wired Remote Controller
Enter/Cancel
To Next Page
