Growatt AXE 5.0L User Manual

Shenzhen Growatt New Energy CO.,Ltd
21
circuit failure
should stop using battery.
User should contact installer to
repair battery
7 Technical Specifications
Functional parameters of AXE 5.0L Energy Storage System are as shown below:
No.
Items
Specification
1
Battery Module
AXE 5.0L-C1
2
Nominal Capacity/Energy
100Ah/5.0kWh
3
Rated Capacity/Energy
90Ah/4.6kWh
4
Nominal Voltage
51.2V
5
Operating Voltage
46.4 - 57.6V
6
Max. charging current(25℃)
60A
7
Max. discharging current(25℃)
60A
8
Battery Type
Cobalt Free Lithium Iron Phosphate (LFP)
9
Operative temperature range
0℃~50℃
10
Recommended operating temperature
10℃~30℃
11
Storage conditions
Temperature: -10°C ~ +50°C
-20℃～45℃
Humidity：5%~95%RH
Within six months after initial charge
12
Cooling
Natural cooling
13
Dimension (W/D/H)
（650±2 ）/（350±2 ）/（140±2 ）mm
14
Weight
44±2kg
15
Installation
Floor standing installation
16
Ingress protection
IP 20
17
Cell safety certification
IEC62619/UL1973
18
PACK safety certification
UL1973/CE/FCC/Rohs
19
UN transportation test standard
UN38.3
20
Communication port
CAN/RS485
21
Single cluster in parallel
Max.10 PACKs
22
Multiple clusters in parallel
Max.8 Clusters
23
Maximum output current of single cluster
150A
