EXTERNAL CONTROL
109
EXTERNAL CONTROL
The rear panel has 3 signal output connectors.
These connectors are used for external control
from the menu of this product by using the
external signal that includes amplified external
voltage, amplified external signal as well as
synchronization frequency.
Note that prior to operation, it is required to
implement insulation process for external circuit.
For example, while connecting to I/O signals of
ASR-2000, be sure to have double insulation
process for live parts in advance.
Furthermore the state output is always on. The
following chapter will give a brief overview each
of these connectors.
Using External Control I/O .................................. 110
Using External Signal Input Function .................. 111
EXT GAIN - AC+DC-EXT and AC-EXT mode .................. 112
EXT ADD - AC+DC-ADD and AC-ADD mode ................. 113
EXT Sync - AC+DC-Sync and AC-Sync mode ....................... 113
EXT Voltage - AC-VCA mode ................................................... 114
Compiling Arbitrary Waveform Input ................... 115
Manage Arbitrary Waveform Settings ........................................ 122
