GW Instek ASR-2000 Series User Manual

ASR-2000 Series User Manual
150
Wave
SIN, SQU, TRI, ARB1 - 16
11. Go to the Jump To setting and choose which
step to jump to, or turn the setting off.
Step
ON, OFF, 0 ~ 999
12. Go to the Jump Cnt setting and set the number
of times the current step will loop.
Jump Cnt
1 ~ 9999, 0
Note: A setting of 0 will set the
number of jump step to be infinite.
13. Go to the Branch 1/2 setting and set a step to
branch to.
Branch 1, 2
ON, OFF, 0 ~ 999
14. Go to the Term setting and set the step
termination setting. CONTI will automatically
go to the next step at the end of the step. END
will return to step 0. HOLD will stay at the
current step until you allow the sequence to
continue to the next step.
Term
CONTI, END, HOLD
15. Go to the Sync Code setting and set the
synchronous code when the step has started.
Sync Code
LL, LH, HL, HH
16. Go to the ON Phs setting and set the starting
phase of the step. The Fixed indicates user-
defined degree.
ON Phase
Free, Fixed
