Haier LT22R3CW User Manual

Getting Started
Digital LCD / LED LCD Television Instruction Manual EN-18
Note
You can get information from the TV shop or O
internet.
Operation
Press A MENU button.
Press B  button to select TUNING menu, press 
button to enter.
Press
C  button to select Software Upgrade item.
Press
D  button to set it as On. (The default is O)
The Start Upgrade item can be selected.(The default
E
is grey and cannot be selected).
13%
Press EXIT to cancel download
Press F  button to select the Start Upgrade option
and use OK button to enter. Then the TV will restart
and search the upgrade information.
Note
If the upgrade information is received, the TV will O
begin to upgrade. Or else, the TV will be back the
DTV source.
Load the receiver identification. This process may
G
also take several minutes. You can press EXIT button
to cancel the download and your TV set will be back
the DTV source.
100%
15%
Press EXIT to cancel download
Updating in progress - Do not turn off the TV
After the download has finished, your TV set will H
enter burning state and the indicator light is shining.
The menu 4 of right appears.
The set will be back the DTV source when the update is
completed.
USING YOUR TV
How to select the TV program
Using Program number button Enter the channel A
number with the number keypad on the remote
control.
Using
B P+/P- button.
Press the P+/P- button to select a channel number.
HOW to adjust volume
Press V+/V- button on the remote control or the side of
the TV to adjust the volume level.

Haier LT22R3CW Specifications

General

Audio system	Nicam
RMS rated power	5 W
Built-in subwoofer	No
Number of speakers	2
Comb filter	3D
Display diagonal	22 \
Display brightness	350 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Viewing angle, vertical	170 °
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Supported graphics resolutions	1366 x 768
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	20 - 80 %
Operating temperature (T-T)	5 - 35 °C
Number of OSD languages	24
On Screen Display (OSD) languages	BUL, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUM, RUS, SLV, SWE, TUR
RS-232 ports	0
SCART ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	150 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	60 W
Product color	Black
Tuner type	Analog
Analog signal format system	PAL, SECAM, SECAM B/G, SECAM D/K, SECAM L
