NAVIGATOR 550M, 800M, 1000M CENTRIFUGAL OPERATOR'S MANUAL
5.12 Lubrication
Recommended lubrication is shown in following tables.
Use ball bearing grease (lithium grease No. 2)
Note: If the sprayer is cleaned with a high pressure cleaner or fertilizer
has been used, we recommend lubrication of all sections. See
Eagle™ manual for boom greasing.
Navigator 550M Centrifugal (Shown)
1. Pump
2. P.T.O. (P.T.O. driven pumps only)
3. Idler arm (Belt driven pumps only)
4. Hitch Jack
5. Wheel Bearings
6. Tandem Axle (optional/not shown)
Position on
sprayer
Oil
Grease
Operation
hours
Page to fi nd more
information
Winter protection
or off-season
storage
POS.
Fig. 29
5
4
1
3
2
6
