disPlAy of the receiver
DMS800 MANUAL
92
10.2.2 MUTE indicator
The audio output is muted. The
light ring (11) lights up red.
As the power supply and the HF
section remain switched on, no
interference is audible.
10.2.3 Antenna indicator
The DSR800 receiver is a specially developed, digital True Diversity receiver
withintegratedantennasplitter.Theantennaeld(H)displaystheantenna
currently active.
10.3 Status and warning messages
This function draws attention to critical operating conditions of the system
using optical warning messages.
Which warning messages are displayed can be set in the
UTILITY  STATUS menu. If one of the selected operating conditions
occurs, the light ring on the receiver changes from green to red and a cor‑
responding status display is shown on the display. The warning messages
appear in order of urgency.
Dependingonthetypeofwarning,thetopeldofthedisplaycontinuously
displays a large warning for at least 5 seconds. A small warning remains in
thebottomdisplaylineuntilthewarningisconrmed.Theselectedwarning
functions are active in LOCK mode and in SETUP mode.
The corresponding warning messages can be cleared by tapping the
SELECT wheel.
MUTE indicator
Antenna indicator
Messages
