Vi1000 USER MANUAL
16.9 16.9: MENU > SETTINGS
16.9: MENU > SETTINGS
Set Meter In
Point
Determine the metering
point for the input
channel level meters.
There are four choices for the input meter tap, from
left to right: After the analogue mic gain (before digital
trim and lters); after the digital trim and lters (before
the Gate/EQ/Dynamics); after the Gate/EQ/Dynamics
(before the fader); after the fader.
CHAN F Key Range Low Range High
Choose the function
of the channel ‘F’ key
as either Input 1/2
selection, or Strip Lock.
In ‘Input 1/2’ mode, the F-key is mapped to the Input 1/2
selection control in the input section of the channel strip,
and works in parallel with this.
In ‘Strip Lock’ mode, the F-key allows any input or
master bay fader to be locked to its current function,
regardless of layer changes.
Input 1/2 Strip Lock
Set Delay Units
Change the units
used in input, output,
and monitoring delay
adjustments.
You can choose between milliseconds, metres, or feet
and inches.
EQ bandwith
units Range Low Range High
Choose the the unit
for bandwidth controls
in the EQ sections
throughout the console
Selected either Octaves or Q-factor (dened as the ratio
of frequency to bandwidth). The direction of the control is
reversed between the two settings: In Q mode, clockwise
narrows bandwidth, in Octaves mode, clockwise widens
bandwidth.
Q-Factor
Octave Band-
width
Enable NEXT
and LAST Inactive Active
Enable the [NEXT]
and [LAST] cue list
navigation buttons
nearest the operator.
[NEXT]/
[LAST] at
front of desk
disabled
[NEXT]/
[LAST] at
front of desk
enabled
DANTE / MADI
Select Range Low Range High
Switch MADI/Dante
input between MADI
and Dante sources.
See hardware reference 4.2 for operational details.
Dante
selected
MADI
selected
