Vi1000 USER MANUAL
9.1 9.1: MUTE & VCA GRPS > MUTE GROUPS
9.1: MUTE & VCA GRPS > MUTE GROUPS
There are four console mute groups, activated with the [1], [2], [3], and [4] buttons in the MUTE & VCA GROUPS
button group. Both input and output channels can be assigned to mute groups.
When a channel mute is activated by a mute group, the channel’s ON button glows red.
Mute group assignment is started by pressing the MUTE & VCA GROUPS [SETUP] button (see below).
Mute Groups Operation
Mute Setup Inactive Active
Press the MUTE & VCA
GROUPS [SETUP]
button, then chose a
Mute Group button to
congure that group.
The [SETUP] button will glow blue when pressed. The
chosen mute group master button - [1], [2], [3], or [4]
- will glow red when you select that group. Press the
[SOLO/SEL] key of any channels (input and/or outputs)
to be assigned to the selected mute group, then press
[SETUP] again to exit the conguration mode.
Normal
Mute Setup
Mode
Mute Group 'n' Inactive Active
Press to activate / select
a Mute Group.
In normal use, the mute groups selectors will activate
the chosen mute group (mute those channels). In setup
mode they select a mute group to be set up.
Normal
Mute Group
Selected
