Pocket Series User Manual
10
obvious temperature difference.
Ironbow
The target is colored as heated iron.
Red Hot
The hot part is red-colored in view.
Fusion
The hot part is yellow-colored and the cold part is purple-colored in
view.
Rain
The hot part in the image are colored, and the else is blue.
Blue Red
The hot part in the image is colored red, and the else is blue.
3. Press Back to exit the setting interface.
3.4 Adjust Display Temperature Range
Set a temperature range and the palette only works for targets within the temperature range. You
can adjust the temperature range.
Steps
1. Tap Menu, and select .
2. Select auto adjustment or manual adjustment .
a. Tap on an interest area of the screen. A circle is
displayed around the area, and the temperature range
readjusts to show as many details of the area as
possible.
b. Tap on the value on screen to lock or unlock a value.
c. Scroll the adjustment wheel on the screen to fine-
To Next Page
