Hikmicro THUNDER User Manual

Thermal Image Scope User Manual
17
5.3 Set Crosshair Color
The function can change the color of the crosshairs in range table correction display, trajectory
correction display, and distance measurement display.
Before You Start
Enable range table correction first.
Steps
1. In the view mode, hold to show the menu.
2. Select and press to switch the color of crosshair. White, Green, and Red are
selectable.
3. Hold to save and exit.

Hikmicro THUNDER Specifications

General

Pixel Pitch	12 μm
Frame Rate	50 Hz
Aperture	F1.0
Record Video	Yes
Capture Snapshot	Yes
Wi-Fi	Yes
Display	0.39" OLED
Magnification	1x
Response Waveband	8 μm to 14 μm
Lens (Focal Length)	19mm
Battery Type	Rechargeable Li-ion
Power Supply	DC 5V/2A
Operating Temperature	-20°C to +50°C
Reticle	Yes
Storage Temperature	-30 °C to 60 °C (-22 °F to 140 °F)
