Hikmicro THUNDER User Manual

Thermal Image Scope User Manual
21
7.3 Export Files
This function is used to export recorded videos and captured pictures.
Before You Start
Turn off hot spot function.
Steps
1. Connect the device and PC with cable.
Note
Make sure the device is turned off when connecting the cable.
2. Open computer disk and select the disk of device. Go to DICM → 100EZVIZ.
3. Select and copy the files to PC.
4. Disconnect the device from your PC.
Note
● The device displays images when you connect it to PC. But functions such as recording,
capturing and hot spot are disabled.
● When you connect the device to PC for the first time, it installs the drive program
automatically.

Hikmicro THUNDER Specifications

General

Pixel Pitch	12 μm
Frame Rate	50 Hz
Aperture	F1.0
Record Video	Yes
Capture Snapshot	Yes
Wi-Fi	Yes
Display	0.39" OLED
Magnification	1x
Response Waveband	8 μm to 14 μm
Lens (Focal Length)	19mm
Battery Type	Rechargeable Li-ion
Power Supply	DC 5V/2A
Operating Temperature	-20°C to +50°C
Reticle	Yes
Storage Temperature	-30 °C to 60 °C (-22 °F to 140 °F)

Summary

Legal Information

Legal Disclaimer

States product is provided "as is" and limits manufacturer liability for damages.

Regulatory Information

FCC Information

EU Conformity Statement

Industry Canada Compliance

Symbol Conventions

Danger Symbol

Symbol indicating a hazardous situation that could lead to death or serious injury.

Caution Symbol

Symbol for potentially hazardous situations causing equipment damage or data loss.

Safety Instruction

Laws and Regulations

Power Supply Guidelines

Battery Safety

Precautions for battery replacement, charging, and disposal to prevent explosion hazards.

Device Maintenance

Procedures for maintenance, component replacement, cleaning, and service center contact.

Operating Environment

Emergency Procedures

Actions to take in case of smoke, odor, or noise, including immediate shutdown and service contact.

Chapter 1 Overview

Main Functions

Lists key functionalities such as distance measurement, temperature tracking, and image correction.

Button Functions

Chapter 2 Preparation

Cable Connection

Battery Installation

Securing the Device

Powering On/Off

Menu Navigation

Explains how to access and navigate the device's On-Screen Display (OSD) menu.

Chapter 3 Image Settings

Adjusting Diopter

Steps to adjust the focus ring for a clear view of the OSD text or image.

Brightness Adjustment

Contrast Adjustment

Palette Settings

Defective Pixel Correction

Steps to locate and correct pixels that are not functioning as expected.

Flat Field Correction

Picture-in-Picture Mode

Digital Zoom Adjustment

Chapter 4 Highest Temperature Tracking

Highest Temperature Marking

Explains how the device detects and marks the spot with the highest temperature.

Chapter 5 Aiming Point Settings

Range Table Calibration

Enables the range table for accurate aiming at targets.

Trajectory Correction

Corrects trajectory for accurate shooting by marking offsets between crosshairs.

Chapter 6 Measure the Distance

Distance Measurement Overview

Details how the device measures the distance between the target and the observation point.

Target Setup for Measurement

Select target type and set target height for accurate distance calculation.

Aligning Top Measurement Mark

Guides on positioning the top mark at the target's edge for measurement.

Aligning Bottom Measurement Mark

Guides on positioning the bottom mark at the target's edge to complete measurement.

Viewing Measurement Results

Chapter 7 Picture and Video

Capturing Still Images

Recording Video Clips

Exporting Media Files

Procedures for transferring captured pictures and videos to a PC.

Chapter 8 Client Software Connection

T-Vision App Integration

Connects the device to the T-Vision mobile app via hot spot for remote control.

Chapter 11 Maintenance

Device Firmware Upgrade

Restoring Device Defaults

Chapter 12 Frequently Asked Questions

Image Clarity Issues

Capture/Recording Failures

PC Device Identification Issues
