DS-1200KI/1006KI Keyboard User Manual
22

The preset/patrol/pattern must be pre-configured.

Whether PTZ functions are available or not depends on the capabilities of speed domes. If the
speed domes do not support a PTZ function, the keyboard does not respond.
Call Scenes
Purpose:
For the MVC, video wall controller, and decoder added to the keyboard, you can configure the
scene via the client software first and follow the steps below to switch the scene.
The scene of the video wall must be pre-configured for the decoder or MVC via client software.
MAG by IP
The keyboard can connect with the matrix access gateway, and realize the video wall control, PTZ
control, etc.
DEV: 2 WALL: 1
MON: 2 [02]
CAM: 6
PRESET: 1
WALL: 1
DEV: 1
SCENE: 2

HIKVISION DS-1006KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	RS-232 + RS-422 + RS-485
Recommended usage	Office
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Curved
Operating voltage	12 V
Power source type	DC
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	193 mm
Width	435 mm
Height	110 mm
Keyboard weight	1000 g
Keyboard dimensions (WxDxH)	435 x 193 x 110 mm
