HIKVISION DS-1600KI Quick Start Guide

3. Click Video Wall.
4. Select a window on the video wall interface.
5. Click
.
6. Select the date as you desired.
Figure 4-11 Video Wall Playback
7. Oponal: You can switch channel by two ways.
In keyboard panel
Enter the serial number in the numeric panel, and click .
In the list a. Click List
b. Select a camera in the list.
Note
The channel of the selected window must be from a decoding device.
8. Drag the slider to set required playback me.
9. Use the toolbar to perform playback operaons, including stop playing video, start/pause
playing video, slow forward speed, and fast forward speed.
4.3 Video Playback
The videos stored in the encoding device within 24 hours can be played back on the keyboard.
Steps
1. Click Keyboard.
2. Click
.
3. Click Playback on the menu to enter the play back interface.
4. Select the date as you desired.
DS-1600KI Keyboard Quick Start Guide
19

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
