HIKVISION DS-1600KI Quick Start Guide

-
Tap List, and select a channel to preview.
5.
Oponal: Switch the channel.
-
Enter 0+ to stop previewing.
-
Tap to preview the live video of the previous input camera channel on the selected output
monitor.
-
Tap
to preview the live video of the next input camera channel on the selected output
monitor.
6.
Oponal: Tap to close all the live view windows. You can tap to perform the following
operaons.
Icon Descripon
Full • Tap Full to have a full-screen preview of the live video of corresponding camera
on the window.
• Double-tap the window to have a full-screen preview.
Capture Select a window and tap Capture to save pictures to a USB ash drive or FTP
server.
Note
You can also press the buon on the joysck to capture pictures.
Record Select a window and tap Record to save records to a USB ash drive or FTP server.
View Tap View to view parameters of the camera on live view.
Note
If you perform operaons of capturing pictures or recording videos, make sure to connect the
keyboard with a USB ash drive, or provide a valid and correct network connecon between PC
(running FTP server) and the keyboard, and set the FTP parameters of keyboard correctly. Refer
to Set Storage for FTP
conguraon.
5.1.4 Video Wall Playback
Steps
1. Tap on the iSecure main page, and select Video Wall.
2. Select a display window, tap
in the upper-right corner, and select Playback.
DS-1600KI Keyboard Quick Start Guide
28

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
