User Manual of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
Figure 5-33 Linkage Method
5.6.5 Configuring Alarm Output
Steps:
1. Enter the Alarm Output Settings interface:
Configuration>Advanced Configuration> Events > Alarm Output
2. Select one alarm output channel in the Alarm Output drop-down list. You can
also set a name for the alarm output (optional).
3. The Delay time can be set to 5sec, 10sec, 30sec, 1min, 2min, 5min, 10min or
Manual. The delay time refers to the time duration that the alarm output remains in
effect after alarm occurs.
4. Click to enter the Edit Schedule Time interface. The time schedule
configuration is the same as the settings of the arming schedule for motion detection
Refer to Step 2 Set the Arming Schedule for Motion Detection in Section 6.6.1.
5. You can copy the settings to other alarm outputs.
6. Click to save the settings.
