4. Position the cursor on AREA SEL. You can set 4 separate
monitor areas at a time.
5. Select one of the monitor areas and set the values of TOP,
BOTTOM, LEFT and RIGHT to define its size and position. You
can see the frame of the area shown on the screen while
defining the values.
6. Return to MAIN MENU and click SAVE ALL.
7. You can find the MONITOR AREA frame taking effect after
you exit the main menu.
Note: The MONITOR AREA frame can only take effect when
there are BLOCK DISP panes being configured.
4.9 Privacy Mask Settings
Purpose:
You can set privacy masks on the live view screen to cover certain
areas where don’t need to be viewed or recorded.
The size, color and transparency of the areas are adjustable.
Steps:
1. Move the cursor to PRIVACY, set it as ON and press the
button to enter PRIVACY submenu.
2. Position the cursor on AREA SEL and select one mask.
3. Set the values of TOP, BOTTOM, LEFT and RIGHT to define
the size and position of the privacy mask.
4. Select the color and the transparency value for the privacy
mask. Turn on MOSAIC if you want to set the mask as mosaic.
