HIKVISION DS-2DE2A404IW-DE3 User Manual

User Manual of Network PTZ Camera
© Hikvision
96
Figure 6-48 RS-232 Settings
2. Configure the Baud Rate, Data Bit, Stop Bit, Parity, Flow Control, and Usage.
If you want to connect the camera through RS-232 port, the parameters of the RS-232 should
be exactly the same with the parameters you configured here.
3. Click to save the settings.
RS-485
Purpose:
The RS-485 serial port is used to control the PTZ of the camera. The configuring of the PTZ
parameters should be done before you control the PTZ unit.
Steps:
1. Enter RS-485 Port Setting interface:
Configuration> Advanced Configuration> System > RS-485
Figure 6-49 RS-485 Settings
2. Set the RS-485 parameters and click to save the settings.
The Baud rate, PTZ Protocol and PTZ Address parameters of the camera should be exactly the
same as those of the control device.

HIKVISION DS-2DE2A404IW-DE3 Specifications

General

Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Maximum memory card size	256 GB
Maximum resolution	2560 x 1440 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Type	IP security camera
Placement supported	Outdoor
Sensor type	CMOS
Optical sensor size	1/3 \
Housing material	Aluminum
Voice codecs	G.711, G.722.1, G.726, MP2L2, PCM
Number of users	32 user(s)
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
Minimum illumination	0 lx
