User Manual of Network PTZ Camera
© Hikvision
69
to connect seamlessly and to simplify the implementation of networks in the house and
corporate environments.
With the function enabled, you don’t need to configure the port mapping for each port, and the
camera is connected to the Wide Area Network via the router.
Steps:
1. Enter the UPnP™ settings interface.
Configuration >Network > Basic Settings > NAT
2. Check the checkbox to enable the UPnP™ function.
You can edit the Friendly Name of the camera. This name can be detected by corresponding
device, such as a router.
3. Set the port mapping mode:
To port mapping with the default port numbers:
Choose
To port mapping with the customized port numbers:
Choose
And you can customize the value of the port number by yourself.
Figure 6-6 Port Mapping Mode
4. Click to save the settings.
6.1.2 Advanced Settings
Configuring SNMP Settings
Purpose:
You can use SNMP to get camera status and parameters related information.
Before you start:
Before setting the SNMP, use the SNMP software and manage to receive the camera information
via SNMP port. By setting the Trap Address, the camera can send the alarm event and exception
messages to the surveillance center.
The SNMP version you select should be the same as that of the SNMP software.

HIKVISION DS-2DE2A404IW-DE3 Specifications

General

Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Maximum memory card size	256 GB
Maximum resolution	2560 x 1440 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Type	IP security camera
Placement supported	Outdoor
Sensor type	CMOS
Optical sensor size	1/3 \
Housing material	Aluminum
Voice codecs	G.711, G.722.1, G.726, MP2L2, PCM
Number of users	32 user(s)
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
Minimum illumination	0 lx
