User Manual of Network PTZ Camera
© Hikvision
84
 On the event configuration page, click to show the PTZ control panel or click to hide it.
 Click the direction buttons to control the pan/tilt movements.
 Click the zoom/iris/focus buttons to realize lens control.
 The functions vary depending on different camera models.
6.3.1 Configuring Display Settings
Purpose:
Configure the image adjustment, exposure settings, day/night switch, backlight settings, white
balance, image enhancement, video adjustment, and other parameters in display settings.
 The parameters in Display Settings interface vary depending on different camera models.
 You can double click the live view to enter full screen mode and double click it again to exit.
Steps:
1. Enter the Display settings interface:
Configuration > Image> Display Settings
2. You can select the Scene in the dropdown list with different predefined image parameters.
3. Set the image parameters of the speed dome.
Figure 6-24 Display Settings
Image Adjustment
 Brightness
This feature is used to adjust brightness of the image. The value ranges from 0 to 100.
 Contrast
This feature enhances the difference in color and light between parts of an image. The value
ranges from 0 to 100.
 Saturation
This feature is used to adjust color saturation of the image. The value ranges from 0 to 100.
 Sharpness

HIKVISION DS-2DE2A404IW-DE3 Specifications

General

Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Maximum memory card size	256 GB
Maximum resolution	2560 x 1440 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Type	IP security camera
Placement supported	Outdoor
Sensor type	CMOS
Optical sensor size	1/3 \
Housing material	Aluminum
Voice codecs	G.711, G.722.1, G.726, MP2L2, PCM
Number of users	32 user(s)
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
Minimum illumination	0 lx
