User Manual of Digital Video Recorder
54
The √ means the interface is in use, × means the interface is out of use or the connection is invalid. And the
HDMI, VGA and CVBS can be used at the same time.
For Other Models
For the other models, the priority level for the main and aux output is HDMI/VGA>CVBS. See the table below.
Table 3. 4 Priorities of Interfaces
S.N VGA/HDMI CVBS Main output Auxiliary output
1 √ √ VGA/HDMI CVBS
2 √ × VGA/HDMI
3 × √ CVBS
√ means the interface is in use, × means the interface is out of use or the connection is invalid. And the HDMI,
VGA and CVBS can be used at the same time.
3.2.1
Front Panel Operation
This function is not supported by DS-7200HGHI and DS-7100 series.
Table 3. 5 Front Panel Operation in Live View
Functions Front Panel Operation
Show single screen
Press the corresponding Alphanumeric button. E.g. Press 2 to display only the
screen for channel 2.
Show multi-screen
Press the PREV button.
Manually switch
screens
Next screen: right direction button.
Previous screen: left direction button.
Auto-switch
Press Enter button.
Playback
Press Play button.
3.2.2
Using the Mouse in Live View
Table 3. 6 Mouse Operation in Live View
Name Description
Menu
Enter the main menu of the system by right clicking the mouse.
Single Screen
Switch to the single full screen by choosing channel number from the dropdown
list.
Multi-screen
Adjust the screen layout by choosing from the dropdown list.
Previous Screen
Switch to the previous screen.
Next Screen
Switch to the next screen.
To Next Page
