User Manual of Digital Video Recorder
86
5.5 Configuring VCA Record
Purpose:
The DS-7200/7300/8100/9000 support the VCA (line crossing detection and intrusion detection) triggered
recording.
The VCA settings and VCA event triggered recording is supported by 1 analog camera for DS-
7200/7300/8100HGHI models and 2 analog camers for DS-7200/7300/8100/9000HQHI models.
DS-7100-SH does not support VCA.
Steps:
1.
Enter the VCA settings interface and select a camera for the VCA settings.
Menu> Camera> VCA
Figure 5. 19 VCA Settings
2.
Configure the detection rules for VCA events. For details, see the step 2 in
Chapter 8.5 Detecting VCA
Alarm
.
3.
Click the icon to configure the alarm linkage actions for the VCA events.
Select
Trigger Channel
tab and select one or more channels which will start to record when VCA alarm
is triggered.
Click
Apply
to save the settings
