Specifications
Specifications of DS-8600NI-E8
Model
DS-8608NI-E8
DS-8616NI-E8
DS-8632NI-E8
Video/Audio
input
IP video input
8-ch
16-ch
32-ch
Two-way audio
1-ch, RCA (2.0 Vp-p, 1KΩ)
Network
Incoming bandwidth
50Mbps
100Mbps
200Mbps
Outgoing bandwidth
80Mbps
Remote connection
128
Video/Audio
output
Recording resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720
/60Hz, 1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1KΩ)
Decoding
Live view / Playback
resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
8-ch@720P,
6-ch@1080P
16-ch@4CIF, 12-ch@720P, 6-ch@1080P
Hard disk
SATA
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs
eSATA (Optional)
1 eSATA interface
Capacity
Up to 4TB capacity for each HDD
External
interface
Network interface
2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
Serial interface
RS-232 and RS-485
USB interface
2 × USB 2.0 + 1 × USB 3.0
Alarm in / out
16 / 4 (optionally can be expanded to 16 / 8)
Others
Power supply
100 ~ 240 VAC
Consumption
(without hard disk or
DVD-R/W)
≤ 20 W
≤ 20 W
≤ 20 W
Working
temperature
-10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Working humidity
10 % ~ 90 %
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 ×70 mm ( 17.5"× 18.5" × 2.8")
Weight
(without hard disk or
DVD-R/W )
≤ 8 kg (17.6 lb)

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
