Specifications of DS-7600NI-SE
Model
DS-7604NI-SE
DS-7608NI-SE
DS-7616NI-SE
Video/Audio input
IP video input
4-ch
8-ch
16-ch
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Bandwidth
Incoming
bandwidth
20Mbps
40Mbps
80Mbps
Output
bandwidth
40Mbps
Video/Audio
output
Decoding
resolution
5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIF
HDMI/VGA
output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz
CVBS
(optional)
1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
Audio output
1-ch, RCA (Linear, 1kΩ).
Playback
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
Synchronous
playback
4-ch@720P, 2-ch@
1080P, 1-ch@ 5MP
8-ch@4CIF,4-ch@720P, 2-ch@1080P, 1-ch@5MP
Hard disk
SATA
1 SATA interface for 1
HDD
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External interface
Network
interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
Serial interface
1 RS-485 half-duplex interface
USB interface
2 × USB 2.0
Alarm in/out
(optional)
4/1
Others
Power supply
12V DC
Consumption
≤ 10 W (without hard disk)
Working
temperature
-10 ºC ~ +55 ºC (14 ºF ~ 131 ºF )
Working
humidity
10 % ~ 90 %
Chassis
Stand-alone 1U chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
315 × 230 × 45mm
(12.4 × 9.0 × 1.8 inch)
445 × 290 × 45mm (17.5 × 11.4 × 1.8 inch)
Weight
≤ 2 Kg (4.4 lb) (without hard disk)

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
