HIKVISION DS-7608NI-E2/8P Quick Operation Guide

Quick Operation Guide of Network Video Recorder
39
Specifications of DS-7600NI-SN/P
Model
DS-7604NI-SN/P
DS-7608NI-SN/P
DS-7616NI-SN/P
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
25Mbps
50Mbps
100Mbps
Outgoing bandwidth
40Mbps
Remote connection
32
128
128
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Playback / Live view
resolution
1080P / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Capability
4-ch@720P, 2-ch@1080P
8-ch@4CIF,
4-ch@720P,
2-ch@1080P
8-ch@4CIF, 8-ch@720P,
4-ch@1080P
Hard disk
SATA
1 SATA interface for 1
HDD
2 SATA interface for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 Mbps self-adaptive Ethernet
interface
1 RJ-45 10 /100/1000
Mbps self-adaptive
Ethernet interface
USB interface
2 × USB 2.0
Alarm in/out
(Optional)
4 / 1
PoE
Interface
4 independent 10/100
Mbps PoE Ethernet
interfaces
8 independent 10 /100 Mbps PoE Ethernet
interfaces
Max. Power
35W
120W
Supported Standard
AF
Others
Power supply
48VDC
220VAC
Consumption
(without hard disk
and PoE)
≤ 6W
≤ 10W
≤ 15W
Working
temperature
-10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Working humidity
10 % ~ 90 %
Chassis
1U chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
315 × 230 × 45 mm
(12.4" × 9.0" × 1.8")
445 × 290 × 45 mm
(17.5" × 15.4" × 1.8")
Weight
(without hard disk)
≤ 1 Kg (2.2 lb)

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
