HIKVISION DS-7608NI-E2/8P Quick Operation Guide

Quick Operation Guide of Network Video Recorder
5
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.
This manual is applicable to the models listed in the following table.
Series
Models
DS-7100NI-SL series
DS-7104NI-SL, DS-7108NI-SL
DS-7104NI-SL/W
DS-7100NI-SN series
DS-7104NI-SN, DS-7108NI-SN, DS-7116NI-SN
DS-7104NI-SN/N, DS-7108NI-SN/N, DS-7116NI-SN/N
DS-7104NI-SN/P, DS-7108NI-SN/P, DS-7116NI-SN/P
DS-7600NII-SN series
DS-7604NI-SN, DS-7608NI-SN, DS-7616NI-SN
DS-7604NI-SN/N, DS-7608NI-SN/N, DS-7616NI-SN/N
DS-7604NI-SN/P, DS-7608NI-SN/P, DS-7616NI-SN/P
DS-7600NI-E1/E2 series
DS-7604NI-E1, DS-7608NI-E1, DS-7616NI-E1
DS-7604NI-E1/4P
DS-7604NI-E1/4N
DS-7608NI-E2, DS-7616NI-E2, DS-7632NI-E2
DS-7608NI-E2/8P, DS-7616NI-E2/8P, DS-7632NI-E2/8P
DS-7608NI-E2/8N, DS-7616NI-E2/8N, DS-7632NI-E2/8N
DS-7600NI-SE series
DS-7604NI-SE, DS-7608NI-SE, DS-7616NI-SE
DS-7604NI-SE/N, DS-7608NI-SE/N, DS-7616NI-SE/N
DS-7604NI-SE/P, DS-7608NI-SE/P, DS-7616NI-SE/P
DS-7600NI-V(P) series
DS-7604NI-V, DS-7608NI-V, DS-7616NI-V
DS-7604NI-VP, DS-7608NI-VP, DS-7616NI-VP
DS-7700NI series
DS-7708NI-E4, DS-7716NI-E4, DS-7732NI-E4
DS-7708NI-E4/8P, DS-7716NI-E4/16P, DS-7732NI-E4/16P
DS-8600NI series
DS-8608NI-E8, DS-8616NI-E8, DS-8632NI-E8
NVR Pre-Installation
The NVR is highly advanced surveillance equipment that should be installed with care. Please take into
consideration the following precautionary steps before installation of the NVR.
1. Keep all liquids away from the NVR.
2. Install the NVR in a well-ventilated and dust-free area.
3. Ensure environmental conditions meet factory specifications.
4. Install a manufacturer recommended HDD.
NVR Installation
During the installation of the NVR:
1. Use brackets for rack mounting.
2. Ensure there is ample room for audio and video cables.

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
