17.1 Specifications
17.1.1 DS-96000NI-I16
Model
DS-96128NI-I16
DS-96256NI-I16
Video & Audio
input
IP video input
128-ch
256-ch
Incoming/outgoing
bandwidth
512Mbps/512Mbps
768Mbps/512Mbps
Incoming/outgoing
bandwidth (RAID mode)
400Mbps/400Mbps
512Mbps/400Mbps
Protocol
HIKVISION, ACTi, ARECONT, AXIS, BOSCH, BRICKCOM, CANON, HUNT, ONVIF
(Version 2.5), PANASONIC, PELCO, PSIA, RTSP, SAMSUNG, SONY, VIVOTEK, ZAVIO
Video & Audio
output
HDMI output
Two independent HDMI outputs of 4K resolution. Resolution: 4K (4096 × 2160), 4K (3840 ×
2160) /30Hz, 2K (2560 × 1440) /60Hz, 1080p (1920 × 1080) /60Hz, UXGA (1600 × 1200) /60Hz,
SXGA (1280 × 1024) /60Hz, 720p (1280 × 720) /60Hz, XGA (1024 × 768) /60Hz
VGA output
1-ch. Resolution: 1080p (1920 × 1080) /60Hz, UXGA (1600 × 1200) /60Hz, SXGA (1280 ×
1024) /60Hz, 720p (1280 × 720) /60Hz, XGA (1024 × 768) /60Hz
LCD output (optional)
One 7 inch LCD
Audio output
1-ch. RCA (2.0 Vp-p, 1 KΩ)
Video & Audio
decoding
Video resolution
12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3
MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback
Up to 16 channels
Capability
20-ch @ 1080p
HDD
Interface
16 SATA interfaces supporting hot-plug
Capacity
1TB/2TB/3TB/4TB/5TB/6TB/8TB
RAID
RAID Type
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Network
management
Protocol
IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
Network interface
4, RJ45 10M/100M/1000M self-adaptive Ethernet interface
External
interface
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Serial port
1 RS-232, 1 RS-485, Keyboard
USB interface
Front Panel: 2 × USB 2.0 in; Rear Panel: 2 × USB 3.0
Alarm input/output
16/8
General
Power supply
100 to 240 VAC, 550W
Fan
Redundant dull ball bearing fan; Speed adjustable; Hot-plug
Consumption
(without HDD)
≤ 140W
Working temperature
0 °C to 50 °C (32 °F to 122 °F)
Working humidity
10% to 90%
Chassis
3U
Dimension
(W × D × H)
442 × 494 × 146 mm (17.4 × 19.4 × 5.7 inch)
Weight
(without HDD)
≤16 kg (35.3 lb)

HIKVISION DS-96128NI-I24 Specifications

General

Audio system	2-way
Input bandwidth	576 Mbit/s
Output bandwidth	512 Mbit/s
Maximum resolution	4096 x 2160 pixels
Alarm input channels	16
Video input channels	128 channels
Alarm output channels	8
Supported resolutions	4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, H.265+, M-JPEG, MPEG4
Number of simultaneously playbacked channels	16 channels
Audio RCA inputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
Product color	Black
Rack capacity	4U
Rack mounting	Yes
RAID levels	0, 1, 5, 10
HDD capacity	- GB
HDD interface	SATA
Maximum storage capacity	10 TB
Number of HDDs installed	0
Number of HDDs supported	24
AC input voltage	100 - 240 V
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Display type	LCD

Weight and Dimensions

Depth	528 mm
Width	447 mm
Height	172 mm
Weight	23000 g
