LCD Monitor User Manual
10
Panel Buttons 3.3
Refer to the following figure and table for the description of the buttons on the lower right corner
of the monitor.
Buttons on Panel Figure 3-2
Description of Buttons Table 3-2
Power Supply Connections 3.4
The device provides two power supply connectors: 100 to 240 VAC, and 24 VDC.
Insert the 3-pin power plug into well-grounded power socket of the 100 to 240 VAC connector, or
insert a 4-pin power plug (with adapter) to the 24 VDC power connector.
Power Supply Figure 3-3
Disconnect the power of the monitor if it will not be used for a long time.
Dimensions (unit: mm) 3.5
Refer to the following figure for the dimensions of the monitor:
