2 Terminal and Wiring Descripon
2.1 Terminal Descripon
Figure 2-1 Terminal Descripon
Table 2-1 Descripons
Name Interface Descripon
LAN RESERVED RESERVED
LAN Network Interface
ALARM IN SEN1 Door Contact Detecon Input 1/Door Contact
BTN1 Door Contact Detecon Input 1/Door Contact
SEN2 Door Contact Detecon Input 2/Door Contact
BTN2 Door Contact Detecon Input 2/Door Contact
GND Grounding
AIN1 Alarm Input 1
AIN2 Alarm Input 2
AIN3 Alarm Input 3
AIN4 Alarm Input 4
RS485 485A+ RS-485 Communicaon Interfaces
