Video Intercom Villa Door Station User Manual
34
Ring-Back Tone Settings
Click Intercom → Ringbacktone Settings to enter the settings page.
Click Add to select the ring tone from PC.
Note
Available Audio Format: WAV、AAC, Size: Less than 600 KB, Sample Rate: 8000Hz, Mono.
Press Button to Call
Steps
1. Go to Intercom → Press Button to Call to enter the settings page.
2. Check Call Indoor Station or Call Management Center as the button call target.
Note
If you check Call Indoor Station, you should enter the call indoor station No.
3. Click Save.
Input and Output
Go to Intercom → I/O Settings to enter the settings page.
Figure 5-16 IO Input and Output
Select I/O Input No., Input, I/O Output No. and Output.
Click Save to enable the settings.
5.5.9 Access Control Settings
Door Parameters
Steps
1. Click Access Control → Door Parameters to enter the settings page.

HIKVISION DS-KV6113-PE1 Specifications

General

Color	-
Wall mountable	Yes
Connectivity technology	Wired
Megapixel	2 MP
Supported video modes	720p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RTSP
Product color	Black, Grey
International Protection (IP) code	IP65
LED type	IR
Indoor unit included	No
Outdoor unit power type	DC
Power consumption (typical)	10 W
Operating temperature (T-T)	-40 - 55 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	- \
Operating system installed	Embedded LINUX

Weight and Dimensions

Depth	65 mm
Width	138 mm
Height	27 mm
