HIKVISION DS-KV6113-PE1 User Manual

Video Intercom Villa Door Station User Manual
48
Select Advertising Information, Property Information, Alarm Information or Notice
Information as Type according to your needs.
Start Time/End Time
Click the time icon to specify the start time and end time of a time period to search the logs.
Reset the Settings
Click Reset to reset all the configured search conditiions.
3. Click Search and the matched notice will display on this page.
4. Optional: Click Export to export the notices to your PC.
6.5.4 Upload Armed Information
Steps
1. On the main page, click upper right → Tool → DeviceGuard to enter the page.
2. Enable to arm or disarm the device.
Note
● While device has been added to the client software, the device armed by default.
● When the device is armed, the alarm logs upload to the client software automatically.
● Click Alarm Application → Event Search to search the alarm logs.
3. Optional: Click Arm All or Disarm All to arm or disarm all the device.

HIKVISION DS-KV6113-PE1 Specifications

General

Color	-
Wall mountable	Yes
Connectivity technology	Wired
Megapixel	2 MP
Supported video modes	720p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RTSP
Product color	Black, Grey
International Protection (IP) code	IP65
LED type	IR
Indoor unit included	No
Outdoor unit power type	DC
Power consumption (typical)	10 W
Operating temperature (T-T)	-40 - 55 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	- \
Operating system installed	Embedded LINUX

Weight and Dimensions

Depth	65 mm
Width	138 mm
Height	27 mm
