HIKVISION DS-KV6113-PE1 User Manual

Video Intercom Villa Door Station User Manual
44
Figure 6-3 Card Settings
3. Select Card Type and Card No. Type.
4. Click OK to save the settings.
Result
After issuing the card to the person, the person and card information will display in the Person(s)
with Card Issued list.
6.4.7 Permission Settings
Add Permissions
Steps
1. On the main page, click AccessControlInfo → Access Group to enter the page.
2. Click +Add to pop up the adding dialog box.
3. Configure the parameters.
1) Enter the Name of the permission.
2) Select the Template of the schedule.
3) Check the person to Selected according to your needs.
4) Check the device to Selected according to your needs.

HIKVISION DS-KV6113-PE1 Specifications

General

Color	-
Wall mountable	Yes
Connectivity technology	Wired
Megapixel	2 MP
Supported video modes	720p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RTSP
Product color	Black, Grey
International Protection (IP) code	IP65
LED type	IR
Indoor unit included	No
Outdoor unit power type	DC
Power consumption (typical)	10 W
Operating temperature (T-T)	-40 - 55 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	- \
Operating system installed	Embedded LINUX

Weight and Dimensions

Depth	65 mm
Width	138 mm
Height	27 mm
