HIKVISION HWT-B123-M User Manual

Digital Video Recorder User Manual
103
Figure 6-20 Interface of Playback by Log
6.1.7 Playing Back by Sub-Periods
Purpose
The video files can be played in multiple sub-periods simultaneously on the screens.
Step 1 Go to Menu > Playback.
Step 2 Select Sub-periods from the drop-down list in the upper-left corner of the page to enter the
Sub-periods Playback interface.
Step 3 Select a date and start playing the video file.
Step 4 Select the Split-screen Number from the drop-down list. Up to 16 screens are configurable.
Figure 6-21 Interface of Sub-periods Playback
According to the defined number of split-screens, the video files on the selected date can be divided
into average segments for playback. E.g., if there are video files existing between 16:00 and 22:00,
