Digital Video Recorder User Manual
44
Figure 2-42 Password Configuration of the Camera
Step 5 Click OK to save the settings and exit the interface.
2.8 Configuring Signal Input Channel
Purpose
You can configure the analog and IP signal input types.
Step 1 Go to Menu > Camera > Signal Input Status.
Step 2 Check the checkbox to select different signal input types: HD/CVBS and IP. If you select
HD/CVBS, four types of analog signal inputs including Turbo HD, AHD, HDCVI, and CVBS
can be connected randomly for the selected channel. If you select IP, IP camera can be
connected for the selected channel.
Step 3 Click Apply to save the settings.
You can view the max. accessible number of IP cameras in the Max. IP Camera Number text field.
Refer to the specifications for the max. accessible IP camera number of different models.
2.9 Configuring 5 MP Long Distance Transmission
This chapter is only applicable to HWD-7100MH and HWD-7200MH series DVR.
Purpose
For HWD-7100MH and HWD-7200MH series DVR, you can configure 5 MP long distance
transmission on the Signal Input Status interface.
Step 1 Go to Menu > Camera > Signal Input Status.
