Hikvision Fixed Under Vehicle Surveillance System User Manual
24
As the software is linked with hardware device, you are not
allowed to start multiple software simultaneously by default.
If needed, you can check MultRun, click Save and Quit, and
then copy the software to another directory to start multiple
software in different directories.
Select IN and OUT based on the actual driving direction of the
vehicles at the customs pass.
Select ON or OFF as needed.
Select ON or OFF as needed. The function means to process
image by algorithm, such as removing useless images and
adjusting image brightness and contrast.
Select ON or OFF as needed. With the function enabled, if the
same vehicle is detected, its previous vehicle undercarriage
images will be displayed together with the current image for
comparison. Records within 30 days are available for
comparison.
The port No. for communication between software and
hardware speed detection module. It is already set before
leaving factory, with no need for further adjustment.
The length of image streaming. The figure ranges from 20 to
35, and 25 frames are allowed currently. Keeping the default is
recommended. If you set the figure too large, delay may be
caused for heavy loads of image processing, display, and
transmitting.
3.3.5 Search
The sub-menu of Search includes Search and Watch List.
Figure 3-13 Search Menu
