4.3 SYSTEM CONFIGURATION
This central controller (HYJM-S01H) is connected to H-NET and used for the central control and monitoring of the air conditioners.
The system configuration example is shown in below.
4.4 INSTALLATION PROCEDURE
The installation procedure shall be performed as shown below.
Remote Control
Switch Wiring
Outdoor
Unit1
Outdoor
Unit2
Transmission Wiring
(H-NET)
Remote Control
Group1
Remote Control
Group4
Block1
Remote
Control
Group2
Remote
Control
Group3
Remote
Control
Group5
Block2 Block3
Max.64 remote control groups and
Max 160 indoor units are available.
HYJM-S01H
Wiring
Installation
Preparation at the Site
Start
Test Run
HYJM-S01H
To Next Page
