: Auto swing operation will be started.
(1) (1)
3. Touch “OK” to confirm and return.
4. Touch “Cancel” to cancel the command and return.
6.9 SETTING TEMPERATURE
1. Select the screen of “AC Monitor (All Groups)” or “AC Monitor (Block)”. Select the group to set by touching the group button.
2. Slide up, the temperature is increased by 1°C. (Max. 30°C).Slide down, the temperature is decreased by 1°C.
• At Cooling, Dry and Fan operation: Min. 19°C
• At Heating operation: Min. 17°C
AC Monitor (All Groups) AC Monitor (Block)
(2)(3)
LCD
indication
COOL
DRY
Angle range
HEAT
FAN
Angle range
NOTE
This function (swing louver direction) may not be set depending on the unit model.
Louver position on LCD and the actual louver position do not always match during the auto swing operation.
The louver may not stop immediately after the switch is pressed.
•
•
•
HYJM-S01H
