Viewing IP addresses
T
o view the existing IP addresses, navigate to Network Configuration > IP
Addresses.
The following table describes the fields on this page:
Field / Item Description
IP Addresses This field contains the IP address for the Admin and File services or for server/
cluster node management.
Label This field contains the name of the EVS (virtual server) which is assigned to
the IP address.
Type
This field contains the type of services or configuration of the server:
• Admin
- an IP address associated with the Administrative Services for the
cluster. Administration Services IP address can be on the public data
network or on the private management network.
• File serving - an IP address associated with the File Services for the
cluster. File Services IP addresses must be on the public data network.
• Node - the IP address associated with the physical cluster node. As File
and Administrative services can migrate between nodes, the Cluster Node
IP address communicates with the node instead of a service.
Port This field contains the interface in use by the IP address:
• agX identifies one of the file serving aggregation interfaces
• eth-agX identifies one of the Aggregate Linux interfaces
• agX-vlanXXXX identifies one of the VLAN interfaces
• eth0 or eth1 identifies a 10/100/1000 interface for a Hitachi NAS Platform
• mgmnt1 identifies the 10/100 management interface for a Hitachi High
performance NAS Platform
Details
Click this button to view the Modify IP Address page. This page enables the
Administrator to change the interface IPv4 and/or IPv6 settings.
Adding IP addresses
To add an IP address
Configuring IP addresses 49
Hitachi NAS Platform Network Administration Guide
