13
DP65
13
Models: 51F59/A/J 57F59/A/J 65F59/A/J
Cathode-Ray Tube:
R=P16MAB00RFA
G=P16MAB00HHA
B=P16MAB00BMB
Antenna Impedance: 75 Ohm Unbalanced
VHF / UHF / CATV
Receiving Channel: BAND CH
VHF 2~13
UHF 14~69
CPT (B) P.W.B.
EXT. Mid (A-5)~(A-1), 4+
CATV Mid. A~I
CATV Super J~W
CATV Hyper (W+1)~(W+28)
CATV Ultra (W+29)~(W+94)
Intermediate Frequency: Picture l-F Carrier 45.75 MHz
Sound l-F Carrier 41.25 MHz
Color Sub Carrier 42.17 MHz
Video Input: 1 Volt p-p, 75 Ohm
Video Output: 1 Volt p-p, 75 ohm
Audio Input: 470 mVrms, 47 k Ohm
Stereo Audio Output: 470 mVrms, 1 k Ohm
Audio Output Power:
Front: 24 watts per channel at 10% distortion,
8 ohm Impedance. Max output 25 watts.
Anode Voltage:
DP65
31.7±0.2kv (1.59±0.2mA)
Speakers: 51” 2 Woofers - 5 inch (12 cm) round
57” 2 Woofers - 6 inch (16 cm) round
Circuit Board Assemblies:
CPT (B) P.W.B. Digital P.W.B.
CPT (G) P.W.B
Power/Deflection P.W.B.
Sensor P.W.B.
Signal P.W.B.
DCU P.W.B.
CIRCUIT PROTECTION
CAUTION: Below is an EXAMPLE only. See Replacement Parts List for details. The following symbol near the fuse
indicates fast operation fuse (to be replaced). Fuse ratings appear within the symbol.
Example:
SPECIFICATIONS
“RISK OF FIRE - REPLACE FUSE AS MARKED”
The rating of fuse F901 is 10A - 125V.
Replace with the same type fuse for continued protection
against fire.
TABLE OF CONTENTS
DIMENSIONS:
51F710A 57F710A 65F710A
Height (in.) 50-3/8 54-9/16 59-15/16
(mm) 1,279.0 1,385.6 1,521.0
Width (in.) 48-3/4 54 61
(mm) 1,239.0 1,372.0 1,549.0
Depth (in.) 21-7/8 23-5/8 27-7/8
(mm) 557 599.4 708
Weight (lbs.) 187.4 205 309
(kg.) 85 93 140
65” 2 Woofers - 6 inch (16 cm) round
Power Consumption:
• Power Consumption (operating)
51/57/65F59/A/J . . . . . . . . . . . . . . . . . . . . . .187W
• Power Consumption (maximum)
51/57/65F59/A/J . . . . . . . . . . . . . . . . . . . . . .235 W
Brightness: 51” 57” 65”
R=P16LXL00RFA
G=P16LXL00HHA
B=P16LXL00BMB
51F59A/J,57F59A/J,65F59A/J 51F59,57F59,65F59
(W/ ultra shield) 250cd/m2 195cd/m2 150cd/m2
(W/o ultra shield) 310cd/m2 240cd/m2 185cd/m2
Available signal:
Cable ANALOG (NTSC : STD/IRC/HRC)
Air ANALOG (NTSC)
DIGITAL (ATSC:8VSB)
