Hitachi 51F59A User Manual

QUICK REFERENCE PARTS LIST
IC’S & UNITS
TABLE OF CONTENTS
DP65
181
No. Symbol P# Description Function PWB ASSY Remarks
73 E940 AZ00919M CRXT0491007.NRT1-JA
7A PROTECTOR
POWER/DEF
74 E941 AZ00919M CRXT0491007.NRT1-JA
7A PROTECTOR
POWER/DEF
75 E943 AZ00921M CRXT0491010.NRT1-JA
10A PROTECTOR
POWER/DEF
76 E944 AZ00921M CRXT0491010.NRT1-JA
10A PROTECTOR
POWER/DEF
77 E945 AZ00917M CRXT0491004.NRT1-JA
4A PROTECTOR
POWER/DEF
78 E946 AZ00911M CRXT0491.500NRT1-JA
0.5A PROTECTOR
POWER/DEF
79 E947 AZ00916M CRXT0491003.NRT1-JA
3A PROTECTOR
POWER/DEF
80 F901 FN00476 FU-008A-JUI-51MS-U 8A Fuse POWER/DEF
81 F902 FN00464 FU-001A-JUI-51MS-U 1A Fuse POWER/DEF
82 F903 FN00473 FU-005A-JUI-51MS-U 5A Fuse POWER/DEF
83 I601 CP06891 IC TDA8174A Ver. Def out POWER/DEF
84 I701 2362606 IC NJM4558D Gain Amp(Side Pin) POWER/DEF
85 I702 CP04234 IC BA09T Low saturation voltage type 3-pin regulator POWER/DEF
86 I901 CP08515F ANALOG MONOLITHIC IC STR-A6159
POWER IC for stand by
POWER/DEF
87 I902 CP08533 STR-6737M(LF1901)
POWER IC
POWER/DEF
88 I903 CP07851 MONO IC TLP421 OPTOCOUPLER POWER/DEF
89 I904 CP07851 MONO IC TLP421 OPTOCOUPLER POWER/DEF
90 I905 CP07851 MONO IC TLP421 OPTOCOUPLER POWER/DEF
91 I906 CP07851 MONO IC TLP421 OPTOCOUPLER POWER/DEF
92 I907 CP08301 IC STA821M +5.6V Regulator POWER/DEF
93 I908 CP08291 IC STA811M +6.5V Regulator（Heater) POWER/DEF
94 I941 2381343 IC (SE115N) ERROR AMP POWER/DEF
95 IH01 CP07091 IC M62501P HV controler POWER/DEF
96 T701 BT01232 HORIZONTAL OUTPUT TRANSFORMER HOT AREA TRANSFORMER POWER/DEF
97 T702 BZ03061 DRIVE TRANS.-DJ81 H.Drive POWER/DEF
98 T901 BT02271 SWITCHING TRANSFORMER
SW TRANSFORMER
POWER/DEF
99 T902 BT02331 SWITCHING TRANSFORMER
SW TRANSFORMER
POWER/DEF
100 TF01 BT02141 EE22 DYNAMIC FOCUS TRANSFORMER DF TRANSFORMER POWER/DEF DP65 ONLY
101 TF01 BT02143 EE22 DYNAMIC FOCUS TRANSFORMER DF TRANSFORMER POWER/DEF DP65G ONLY
102 TH01 BW03171 FBT HFL1535AP-RC FBT POWER/DEF
103 X901 AJ00835 CC-*****ERZV10D471
SURGE ABSORBER
POWER/DEF
104 E801 EY01353 PJX-CVT3248-1298T Red CPT Socket CPT
105 E851 EY01353 PJX-CVT3248-1298T Green CPT Socket CPT
106 E8A1 EY01353 PJX-CVT3248-1298T Blue CPT Socket CPT
107 Q801 2327471F TRS.2SC3950 (HIT D/E) RED VIDEO OUT CPT
108 Q803 2312372F TRS-2SC3942 RED VIDEO OUT CPT
109 Q804 2312773F TRS-2SA1546(2)M/L RED VIDEO OUT CPT
110 Q805 2312372F TRS-2SC3942 RED VIDEO OUT CPT
111 Q851 2327471F TRS.2SC3950 (HIT D/E) GREEN VIDEO OUT CPT
112 Q853 2312372F TRS-2SC3942 GREEN VIDEO OUT CPT
113 Q854 2312773F TRS-2SA1546(2)M/L GREEN VIDEO OUT CPT
114 Q855 2312372F TRS-2SC3942 GREEN VIDEO OUT CPT
115 Q8A1 2327471F TRS.2SC3950 (HIT D/E) BLUE VIDEO OUT CPT
116 Q8A3 2312372F TRS-2SC3942 BLUE VIDEO OUT CPT
117 Q8A4 2312773F TRS-2SA1546(2)M/L BLUE VIDEO OUT CPT
118 Q8A5 2312372F TRS-2SC3942 BLUE VIDEO OUT CPT
119 QE06 2315381 TRS. 2SA1837 RED VM OUT CPT
120 QE07 2315391 TRS. 2SC4793 RED VM OUT CPT
121 QE56 2315381 TRS. 2SA1837 GREEN VM OUT CPT
122 QE57 2315391 TRS. 2SC4793 GREEN VM OUT CPT
123 QEA6 2315381 TRS. 2SA1837 BLUE VM OUT CPT
124 QEA7 2315391 TRS. 2SC4793 BLUE VM OUT CPT
