REPLACEMENT PARTS LIST
PRODUCT SERVICE NOTE:Components marked with a have special characteristics important to safety.Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
Capacitors: Resistors: Semiconductors:
AL: Aluminum Electrolytic CF: Carbon Film TR: Transistor
CD: Ceramic Disc CC: Carbon Composition DI: Diode
EL: Electrolitic MF: Metal Oxide ZD: Zener Diode
PF: Polyester Film VR: Variable Resistor VA: Varistor
PP: Polypropylene WW: Wire Wound TH: Termistor
PL: Plastic FR: Fuse Resistor IC: Integrated Circuit
TA: Tantalum MG: Metal Grazed
PR: Paper
TM: Trimmer
MC: Mylar
ABBREVIATIONS
TABLE OF CONTENTS
155
DP65
SYMBOL PART No. DESCRIPTION SYMBOL PART No. DESCRIPTION
C043 0800326R CAP.-ELECTRO. 100UF-M 16V
SIGNAL PWB C044 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C045 0893204R CAP 1608CHIP 470PFKB 50V TAPE
CAPACITORS C046 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C001 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C047 0800326R CAP.-ELECTRO. 100UF-M 16V
C002 AA01113R CCC225K06-B-16CT C049 AA01802R CCC103K50-B-16CT MCH18
C003 0893131R CAP 1608CHIP 220PFJCH 50V TAPE C050 0893104R CAP 1608CHIP 2PFCCK 50V TAPE
C006 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) C051 0893182R CERAMIC CAPACITOR(15000PF 16V)
C007 0893204R CAP 1608CHIP 470PFKB 50V TAPE C052 AA01802R CCC103K50-B-16CT MCH18
C008 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C053 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C009 AA01113R CCC225K06-B-16CT C054 0800326R CAP.-ELECTRO. 100UF-M 16V
C010 0893131R CAP 1608CHIP 220PFJCH 50V TAPE C055 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C012 0800326R CAP.-ELECTRO. 100UF-M 16V C056 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C013 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C057 AA01802R CCC103K50-B-16CT MCH18
C014 0800326R CAP.-ELECTRO. 100UF-M 16V C058 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C015 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C066 AA01802R CCC103K50-B-16CT MCH18
C016 0800326R CAP.-ELECTRO. 100UF-M 16V C067 0800326R CAP.-ELECTRO. 100UF-M 16V
C017 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C068 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C018 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C069 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C019 0800326R CAP.-ELECTRO. 100UF-M 16V C308 AA01802R CCC103K50-B-16CT MCH18
C020 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C309 AA01802R CCC103K50-B-16CT MCH18
C021 AA01123R CCC105K10-B-16CT C319 AA01802R CCC103K50-B-16CT MCH18
C022 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C320 AA01802R CCC103K50-B-16CT MCH18
C023 0800326R CAP.-ELECTRO. 100UF-M 16V C321 AA01123R CCC105K10-B-16CT
C024 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE C323 AA00969R CAP.CHIP2125-B-22UF6.3V
C025 0800326R CAP.-ELECTRO. 100UF-M 16V C324 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK
C026 0893213R CAP1608CHIP 2200PFKB 50V TAPE C325 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK
C027 AA01111R CERAMIC CAPACITOR(1.0UF 6.3V) C326 0800334R CAP.-ELECTRO. 220UF 10V
C029 0893205R CAP 1608CHIP 560PFKB 50V TAPE C327 AA00969R CAP.CHIP2125-B-22UF6.3V
C030 AA01802R CCC103K50-B-16CT MCH18 C328 0893122R CAP 1608CHIP 47PFJCH 50V TAPE
C031 0893128R CAP 1608CHIP 150PFJCH 50V TAPE C329 0893131R CAP 1608CHIP 220PFJCH 50V TAPE
C032 0893126R CAP 1608CHIP 100PFJCH 50V TAPE C330 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C033 AA01123R CCC105K10-B-16CT C331 AA01802R CCC103K50-B-16CT MCH18
C034 AA01123R CCC105K10-B-16CT C332 AA01123R CCC105K10-B-16CT
C035 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C333 AA01123R CCC105K10-B-16CT
C036 0800303R CAP.-ELECTRO. 22UF-M 50V C334 AA01802R CCC103K50-B-16CT MCH18
C037 AA01801R CCC682K50-B-16CT C335 AA01802R CCC103K50-B-16CT MCH18
C038 AA01143R CERAMIC CAPACITOR(0.22UF 16V-B) C336 AA01802R CCC103K50-B-16CT MCH18
C039 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C338 AA00969R CAP.CHIP2125-B-22UF6.3V
C040 AA01141R CERAMIC CAPACITOR(0.1UF 16V) C339 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK
