Hitachi 51F59A User Manual

QUICK REFERENCE PARTS LIST
IC’S & UNITS
TABLE OF CONTENTS
180
No. Symbol P# Description Function PWB ASSY Remarks
1 HM01 CZ01171 GP1UM281RK0F IR module CONTROL/CPT
2 I001 CK39652R DIGITAL MONOLITHIC IC (BR24L32FJ-WE2) 4K x 8 BIT EEPROM SIGNAL
3 I002 CK50613U M306V7MJ-0555FP
TV SUB µCON
SIGNAL
4 I003 CK51101R BD87A29FVM Voltage Detector with Watchdog Timer SIGNAL
5 I004 CK37216R MONO IC TK11133CSCL 3.3 V Voltage regulator with ON/OFF switch SIGNAL
6 I005 CK50961R SN74CB3T3306DCUR DUAL FET BUS SWITCH (LEVEL CONVERTER 3.3V <=> 5V) SIGNAL
7 I006 CK50121R IC CD4053BPWR
CMOS Analog Mux/Demux with Logic Level Conversion SIGNAL
8 I007 CK51091R SN74LVC1G3157DCKR SINGLE-POLE, DOUBLE-THROW ANALOG SW SIGNAL
9 I301 CK51381R NJM4580V-TE1 DUAL OPERATIONAL AMPLIFIER SIGNAL
10 I302 CK50051R MAX4788EXS-T 50mA/100mA CURRENT-LIMIT SWITCHES (FOR SD/MMC) SIGNAL
11 I303 CK53509R MM1665AHBE +5.0V Regulator SIGNAL
12 I304 CK37216R MONO IC TK11133CSCL +3.3V Regulator SIGNAL
13 I305 CK50071R TPS62040DGQR +2.5V Regulator SIGNAL
14 I306 CK50071R TPS62040DGQR +1.2V Regulator SIGNAL
15 I307 CK53474R MM1661JHBE +1.8V Regulator SIGNAL
16 I308 CK37218R MONO IC TK11150CSCL +5.0V Regulator SIGNAL
17 I309 CK37218R MONO IC TK11150CSCL +5.0V Regulator SIGNAL
18 I310 CK50961R SN74CB3T3306DCUR
BUS 5V
→3.3V
SIGNAL
19 I501 CK53531U R2S11008FP Audio/Video Selector SIGNAL
20 IA02 CK53441R NJW1173 Audio Control SIGNAL
21 IA03 2004752 TA8200AHQ Audio Out SIGNAL
22 IA04 CP05163S IC SI-3090F(LF1111) +9.0V Regulator SIGNAL
23 IC01 CK53509R MM1665AHBE +5.0V Regulator SIGNAL
24 IK01 CZ01251 STK394-710 Convergence Amp. SIGNAL
25 IK02 CZ01251 STK394-710 Convergence Amp. SIGNAL
26 IK03 CK38436R MONOLITHIC IC BD5245G Reset IC SIGNAL
27 IX01 CK38711U IC TA1360AFG(HIT) RGB Processor SIGNAL
28 IX02 CP05163S IC SI-3090F(LF1111) +9.0V Regulator SIGNAL
29 U303 HC00681 ANALOG/DIGITAL-TU-V2-320A Digital/Analog Tuner SIGNAL
30 U304 HP01351 ATSC_DIGITAL_MODULE_HMB1100HI DTV-S Unit SIGNAL
31 IG01 CK54791U HD64336087A07FPV FC u-com (flash) DIGITAL
32 IG02 CK37051R ANALOG MONOLITHIC IC(BD4729G) +3.3V Reset DIGITAL
33 IJ01 CK53431U SII9023CTU HDMI Receiver DIGITAL
34 IJ02 CK53052R DIGITAL MONOLITHIC IC (S-24CS0 E2PROM(for EDID) DIGITAL
35 IJ03 CK37216R MONO IC TK11133CSCL +3.3V Regulator DIGITAL
36 IJ04 CK53921R WM8520H9GED/RV Audio DAC DIGITAL
37 IJ05 CK50961R SN74CB3T3306DCUR I2C bus switch DIGITAL
38 IR01 CK07633R DIGITAL MONOLITHIC IC (TC90A45F) Sub 2 Line Comb DIGITAL
39 IR02 CK37218R MONO IC TK11150CSCL +5.0V Regulator DIGITAL
40 IR03 CK50071R TPS62040DGQR +3.3V Regulator DIGITAL
41 IR04 CK50071R TPS62040DGQR '+1.8V Regulator DIGITAL
42 IR05 CK53509R MM1665AHBE +5.0V Regulator DIGITAL
43 IR06 CK38436R MONOLITHIC IC BD5245G +5.0V Reset DIGITAL
44 IR07 CK51091R SN74LVC1G3157DCKR Pr Colorimetry Selector DIGITAL
45 IR08 CK51091R SN74LVC1G3157DCKR Pb Colorimetry Selector DIGITAL
46 IR09 CK51091R SN74LVC1G3157DCKR Y Colorimetry Selector DIGITAL
47 IV01 CK38721R ANALOG MONOLITHIC IC(TA1383FG) Sub Video/Chroma DIGITAL
48 IV05 CK37218R MONO IC TK11150CSCL +5.0V Regulator DIGITAL
49 IW01 CK36543U DIGITAL MONOLITHIC IC (MB87M13 FC4 Digital I/P Processor DIGITAL
50 IW02 CK37204R ANALOG MONOLITHIC IC(TA1358) YPbPr Clamp DIGITAL
51 IW03 CK37216R MONO IC TK11133CSCL +3.3V Regulator DIGITAL
52 IW04 CK37211R MONO IC TK11118CSCL +1.8V Regulator DIGITAL
53 IW05 CK38324R DIGITAL MONOLITHIC IC (SN74LVC H Sync Inverter DIGITAL
54 IW06 CK38325R DIGITAL MONOLITHIC IC (SN74LVC V Sync Inverter DIGITAL
55 IW07 CK37216R MONO IC TK11133CSCL +3.3V Regulator DIGITAL
56 IW11 CK51741U EDS1616AGTA-6B-E 16M bit SDRAM DIGITAL
57 IW12 CK51741U EDS1616AGTA-6B-E 16M bit SDRAM DIGITAL
58 IZ01 CK53541U R8J66650FB DVP-X Digital Video Processor DIGITAL
59 IZ02 CK37219R MONO IC TK11115CSCL +1.5V Regulator DIGITAL
60 IZ03 CK53491R MM1663DHBE +3.3V Regulator DIGITAL
61 IS01 CK39652R DIGITAL MONOLITHIC IC (BR24L32FJ-WE2) DCU EEPROM DCU
62 IS04 CK37216R MONO IC TK11133CSCL +3.3V Regulator DCU
63 IS05 CK37052R ANALOG MONOLITHIC IC(BD4742G) DCU Reset DCU
64 IS06 CK38242U DIGITAL MONOLITHIC IC (YGT-043 DCU Gate Array DCU
65 IS07 CK52631U HD64336047A13HV DCU u-com DCU
66 IT01 CK36942R DIGITAL MONOLITHIC IC (CD0031B DCU D/A DCU
67 IT02 CK37061R ANALOG MONOLITHIC IC(NJM4565) DCU LPF DCU
68 IT03 CK37061R ANALOG MONOLITHIC IC(NJM4565) DCU LPF DCU
69 IT04 CK37061R ANALOG MONOLITHIC IC(NJM4565) DCU LPF DCU
70 IT05 CK37061R ANALOG MONOLITHIC IC(NJM4565) DCU Differential Amp DCU
71 IT06 CK37061R ANALOG MONOLITHIC IC(NJM4565) DCU Differential Amp DCU
72 IT07 CK37061R ANALOG MONOLITHIC IC(NJM4565) DCU Differential Amp DCU
DP65
