Hitachi C 12RSH User Manual

English
12
SPECIFICATIONS
Item Model C 12LSH / C 12RSH
Motor Type Series commutator motor
Power source Single-phase AC 60Hz
Voltage (Volts) 120
Full-load current (Amp) 15
Laser Marker Maximum output <1mW CLASS II Laser Product
Wave length 400-700 nm
Laser medium Laser Diode
Applicable Outside Dia. 12" (305 mm)
saw blade Hole Dia. 1" (25.4 mm)
No load speed 3,800/min
Max. Head Turntable Max. sawing dimension
sawing Miter 0 0 Max. Height 4-3/16" (107 mm)
dimension
Max. Width 12-1/4" (312 mm)
or
* Max. Height 4-11/16" (120 mm)
Max. Width 10-3/16" (260 mm)
With aux. board 1" (25 mm)
0 Left 45° Max. Height 4-3/16" (107 mm)
or Max. Width 8-5/8" (220 mm)
Right 45° or
* Max. Height 4-11/16" (120 mm)
Max. Width 7-1/16" (180 mm)
With aux. board 1" (25 mm)
0 Right 57° Max. Height 4-3/16" (107 mm)
Max. Width 6-11/16" (170 mm)
or
* Max. Height 4-3/4" (120 mm)
Max. Width 5-1/8" (130 mm)
With aux. board 1" (25 mm)
Bevel Left 45° 0 Max. Height 2-3/4" (70 mm)
Max. Width 12-1/4" (312 mm)
or
* Max. Height 2-15/16" (75 mm)
Max. Width 10-3/16" (260 mm)
With aux. board 1" (25 mm)
Rigth 45° 0 Max. Height 1-3/4" (45 mm)
Max. Width 12-1/4" (312 mm)
or
* Max. Height 1-15/16" (50 mm)
Max. Width 10-3/16" (260 mm)
With aux. board 1" (25 mm)
Compound Left 45° Left 45° Max. Height 2-3/4" (70 mm)
Max. Width 8-5/8" (220 mm)
or
* Max. Height 2-15/16" (75 mm)
Max. Width 7-1/16" (180 mm)
With aux. board 1" (25 mm)
Left 45° Right 31° Max. Height 2-3/4" (70 mm)
Max. Width 10-7/16" (265 mm)
or
* Max. Height 2-15/16" (75 mm)
Max. Width 8-11/16" (220 mm)
With aux. board 1" (25 mm)
Right 45° Right 45° Max. Height 1-3/4" (45 mm)
Max. Width 8-5/8" (220 mm)
or
* Max. Height 1-15/16" (50 mm)
Max. Width 7-1/16" (180 mm)
With aux. board 1" (25 mm)
Right 45° Left 31° Max. Height 1-3/4" (45 mm)
Max. Width 10-7/16" (265 mm)
or
* Max. Height 1-15/16" (50 mm)
Max. Width 8-5/8" (220 mm)
With aux. board 1" (25 mm)
Miter sawing range Left 0° – 46° Right 0° – 57°
Bevel sawing range Left 0° – 45° Right 0° – 45°
Compound sawing range Left (Bevel) 0° – 45°, Left (Miter) 0° – 45°, Right (Miter) 0° – 31°
Right (Bevel) 0° – 45°, Right (Miter) 0° – 45°, Left (Miter) 0° – 31°
Net weight C12LSH 66.1 lbs. (30 kg) C12RSH 63.9 lbs. (29 kg)
Cord 2 Conductor type cable 6ft. (1.8 m)
